EV7 600 series

EV7 600 series

Thermotimers for electric ovens
EV7 600 series is a range of thermotimers for the management of electric ovens.
Available in compact 72 x 72 mm format. The user interface consists of a display that changes colour according to the figure displayed (time and temperature), 6 keys and IP54 protection for easy cleaning.
Some have the steam management (injection and airhole) and the “programmed daily switch on” function; all have the “cooking timer” function.
The controller is built into the front of the panel with screwed-in brackets.
Technical sheet
Generate PDF

Technical Features

1 output thermotimers

EV7601J6EV7611J6
Power supply
24/230 VAC
Analog inputs
room probe (J/K)
Digital outputs (electromechanical relays; res. A @ 250 VAC)
temperature regulation16 A16 A
Other features
real time clock
alarm buzzer
“programmed daily switch on” function
“cooking timer” function

Notes
None.

Available options
None.

3-output thermotimers

EV7613J7EV7603J7
Digital outputs (electromechanical relays; res. A @ 250 VAC)
load 2 (default steam injection) (1)8 A8 A
load 3 (default fan) (2)8 A8 A
temperature regulation16 A16 A
Other features
real time clock
alarm buzzer
“programmed daily switch on” function
“cooking timer” function
Power supply
230 VAC
Analog inputs
room probe (J/K)
Digital inputs (for NA/NC contact)
multipurpose

Notes
(1)configurable for steam injection, acoustic or airhole
(2)configurable for fan or acoustic.

Available options
None.
