EVJ 800

EVJ 800

Controllers for blast chillers
Controllers in the EVJ 800 range are capable of performing blast chilling and blast freezing cycles in an intuitive way, both temperature and time controlled, with hard/soft function. This versatile product provides users with a range of special cycles such as pre-cooling, fish sanitation and ice cream hardening. The outputs are highly configurable thus making it possible to manage the loads needed to run thawing cycles, needle probe heating and cabinet sterilisation. The series includes a model in split version with a 0-10 V analogue output for control of EC modulating fans.
The controllers are available in the compact version or in the split version; the latter includes the "Basic Split" models, equipped with configurable full-sealed relays. The user interface has a 2.8 inch colour graphic display, capacitive keys and an IP65 front with a continuous surface. The controller can be fitted to the panel in the conventional way, built into the front, or concealed under the panel (if made of glass or methacrylate), ensuring high cleaning and hygiene standards.
Users can interact remotely with their equipment using the EPoCA® cloud platform with Wi-Fi or Ethernet connectivity (which also enables alternative or parallel control through MODBUS TCP). Onsite, they can interact from a mobile device with the EVconnect® app which uses Bluetooth Low Energy connectivity. For more details, compare all the connectivity options in the Technical Data table and consult the sections of our website: Products/ Management and Monitoring Systems and Products/ Connectivity Devices.
Technical sheet
Generate PDF

Declaration of conformity to the CE directives

Advantages & Main Features

2.8 inch colour graphic display
Available in the compact and split version
Interaction with the unit from mobile devices through the EVconnect app or from the Internet through the EPoCA cloud platform
Management of blast chilling and freezing cycles, both temperature and time controlled, with hard/soft
Management of 4 special cycles
Models with storage of user recipes
Models with full-sealed relays for equipment using hydrocarbons
Electro-mechanical relay for high-power compressors
2 panel installation methods: recessed or concealed under the panel (if made of glass or methacrylate) with personalised keys on the panel surface
User interface with IP65 protection

Technical Features

EVJ 800, compact and split

EVJ805P9VX3EVJ815P9VX3EVJ815P9VX3XXVEVJ825P9PX3EVJS815P9EVJS824P9EXXHEVJS825P9
VERSION
Compact
Split
POWER SUPPLY
115... 230 VAC
ANALOGUE INPUTS
Cabinet probe (PTC/NTC)
Needle probe (PTC/NTC)
Auxiliary probe (PTC/NTC)
DIGITAL INPUTS
Door switch
Multi-purpose
CONFIGURABLE INPUTS (ANALOGUE OR DIGITAL)
Auxiliary probe (PTC/NTC) or door switch/multi-purpose
0-10 V ANALOGUE OUTPUT
Evaporator fans (EC)
DIGITAL OUTPUTS (electro-mechanical relays; A res. @ 250 VAC)
Compressor30 A30 A30 A30 A30 A30 A30 A
Defrost8 A8 A8 A8 A8 A8 A8 A
Evaporator fans8 A8 A8 A8 A8 A8 A8 A
Condenser fans (configurable)5 A5 A5 A5 A8 A8 A8 A
Needle probe heater (configurable)5 A5 A5 A5 A8 A8 A8 A
COMMUNICATIONS PORTS
MODBUS TTL
CONNECTIVITY
RS-485 MODBUS RTU (optional through the EVlinking RS-485 module)
Bluetooth Low Energy for EVconnect app (built-in)
Bluetooth Low Energy for EVconnect app (optional through the EVlinking BLE module)
Wi-Fi EPoCA/MODBUS TCP (optional through the EVlinking Wi-Fi module powered by controller)
Wi-Fi EPoCA/MODBUS TCP (optional through the EVlinking Wi-Fi module with separate 12 Vac/15 Vdc power supply)
Ethernet EPoCA/MODBUS TCP (optional through the EVCO gateways EV3 Web or EVD Web)
OTHER STANDARD FEATURES
Clock
Alarm buzzer
Management of blast chilling and blast freezing cycles, both temperature and time controlled
Management of special cycles (fish sanitation, thawing and ice cream hardening)
Ready-to-use OEM recipes
Storage of user recipes (up to 20)

Notes
(1)The two options are mutually exclusive and can be selected by parameter.

Available options
Plug-in screw terminal blocks (fixed-screw as standard).

EVJ 800 "Basic Split"

EVJS824P9
VERSION
Split
POWER SUPPLY
115... 230 VAC
ANALOGUE INPUTS
Cabinet probe (PTC/NTC)
Needle probe (PTC/NTC)
DIGITAL INPUTS
Door switch
CONFIGURABLE INPUTS (ANALOGUE OR DIGITAL)
Auxiliary probe (PTC/NTC) or multi-purpose
DIGITAL OUTPUTS (full-sealed relays; A res. @ 250 VAC)
Configurable (default compressor)16 A
Configurable (default evaporator fans)5 A
Configurable (default defrost)8 A
Configurable (default condenser fans)16 A
COMMUNICATIONS PORTS
MODBUS TTL
CONNECTIVITY
RS-485 MODBUS RTU (optional through the EVlinking RS-485 module)
Bluetooth Low Energy for EVconnect app (optional through the EVlinking BLE module)
Wi-Fi EPoCA/MODBUS TCP (optional through the EVlinking Wi-Fi module with separate 12 Vac/15 Vdc power supply)
Ethernet EPoCA/MODBUS TCP (optional through the EVCO gateways EV3 Web or EVD Web)
OTHER STANDARD FEATURES
Clock
Alarm buzzer
Management of blast chilling and blast freezing cycles, both temperature and time controlled
Management of special cycles (fish sanitation, thawing and ice cream hardening)
Ready-to-use OEM recipes
Storage of user recipes (up to 20)

Notes
None.

Available options
None.
